Cutter Suction Dredger IHC Beaver 22/20

Cutter Suction Dredger IHC Beaver 22/20

• Build year: 2003
• Total dry weight approx.: Ton. 108
• Overall width: mt. 7,95
• Overall lenght: mt. 32,50
• Average draught: mt. 1,50
• Suction diameter:  550 mm
• Delivery diameter: 500 mm
• Dredging pump : Type IHC HR/MD 91-19-45 Power at shaft : 690 kW
• Prime mover: CATERPILLAR 3508 B-SCAC power at 1.600 rev/min 746 Kw (1022 hp)
• Auxiliary power: CATERPILLAR 3406 C power at 1.800 rev/min 344,5 Kw (472 hp)
• Cutter : Power at shaft : 175 kW
• Swing winches : Hydraulic operation
• Maximum standard dredging depth: mt. 16,00
• Maximum distance of wastewater: mt. 4.000;
